USBLC6-2P6
This ESD suppressor meets IEC 61000-4-2 ±30kV, EFT 40A, and lightning 5.5A, protecting two high-speed data lines.
- Reverse cutoff voltage (Vrwm) ：5V
- Clamping voltage ：14V
- Peak pulse current (Ipp) ：5.5A
- Peak pulse power (Ppp) ：80W
- Breakdown voltage (VBR) ：6V
- Reverse current (Ir)：80nA
- Product Package ：SOT-666-6
- Packaging Method ：Tape & Reel
- Product Gross weight ：0.032(g)
USD 0.135
26000
