Product Description
Large lead ball screw is mainly composed of screw, nut, ball and circulating device. The screw is a slender shaft with a spiral raceway, and the nut has a corresponding raceway inside, and the ball is located between the raceway of the screw and the nut. When the screw rotates, the ball rolls in the raceway and drives the nut to move in a straight line. The function of the circulating device is to enable the ball to cycle in the closed raceway to ensure the continuity of movement.
For example, just like a spiral track (lead screw) and a slider (nut) with a ball, when the track rotates, the slider moves quickly along the axis of the track, and the ball acts to reduce friction, similar to a small steel ball rolling between the track and the slider.
Product parameters
| Nominal type | Shaft diameter | lead | Pearl diameter | Nut size | Dynamic rated load | Static rated load | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | l | Da | D | A | E | B | L | W | H | X | Q | n | Ca | Coa | |
| SFYR1616-3.6 | 16 | 16 | 2.778 | 32 | 53 | 10.1 | 10 | 52 | 42 | 34 | 4.5 | M6x1 | 1.8x2 | 1073 | 2551 |
| SFYR2020-3.6 | 20 | 20 | 3.175 | 39 | 62 | 13 | 10 | 48 | 50 | 41 | 5.5 | M6x1 | 1.8x2 | 1387 | 3515 |
| SFYR2040-1.6 | 40 | 40 | 3.175 | 39 | 62 | 13 | 10 | 58 | 50 | 41 | 5.5 | M6x1 | 0.8x2 | 653 | 1597 |
| SFYR2550-1.6 | 50 | 50 | 3.969 | 47 | 74 | 15 | 12 | 64 | 60 | 49 | 6.6 | M6X1 | 0.8x2 | 976 | 2495 |
| SFYR2525-3.6 | 25 | 25 | 3.969 | 47 | 74 | 15 | 12 | 78 | 60 | 49 | 6.6 | M6x1 | 1.8x2 | 2074 | 5494 |
| SFYR3232-3.6 | 32 | 32 | 4.762 | 58 | 92 | 17 | 12 | 99 | 74 | 60 | 9 | M6x1 | 1.8x2 | 3021 | 8690 |
| SFYR4040-3.6 | 40 | 40 | 6.35 | 73 | 114 | 19.5 | 15 | 117 | 93 | 75 | 11 | M6x1 | 1.8x2 | 4831 | 14062 |
| SFYR5050-3.6 | 50 | 50 | 7.938 | 90 | 135 | 21.5 | 20 | 45 | 112 | 92 | 14 | M6x1 | 1.8x2 | 7220 | 21974 |
peculiarity
Lead is an important parameter of ball screw. The large lead means that with each turn of the screw, the nut moves up the screw axis by a larger distance. This makes it excellent in devices that require fast, linear motion.
For example, the lead of a normal ball screw may be 5mm, while the lead of a large ball screw may be 20mm or more. At the same speed, the large lead ball screw can achieve faster linear speed, and for some high-speed automation equipment, such as the arm movement of high-speed sorting robots, this feature can greatly improve work efficiency.
Product Display
Size specification
The "2020" in SFY2020 usually represents the nominal diameter and lead of the ball screw. The nominal diameter is 20mm and the lead is 20mm. The larger lead means that the nut moves a larger distance with each turn of the lead screw. This size specification makes it suitable for some equipment requiring fast linear motion.
accuracy level
The product generally has a variety of accuracy levels to choose from. For example, accuracy levels such as C3, C5 may be included. C3 precision is relatively high, suitable for equipment requiring strict positioning accuracy, such as precision machine tools, semiconductor manufacturing equipment, etc. C5 accuracy is slightly lower, but it can also play a good role in some occasions with high speed requirements and relatively less demanding accuracy requirements, such as material handling devices in automated production lines.
Load capacity
It has a certain axial load capacity. Through reasonable ball and raceway design, it can withstand large axial force. The specific load capacity depends on the screw material, the number and diameter of the ball and other factors. When designing the mechanical structure, it is necessary to select the right ball screw according to the actual working load to ensure that it will not be overloaded and damaged in long-term operation.
Transmission efficiency
Large lead ball screw SFY2020 has higher transmission efficiency. Because the ball is rolled between the screw and the nut, the friction coefficient is small, and the energy loss can be effectively reduced compared to the traditional trapezoidal screw. Its transmission efficiency can reach more than 90%, which makes it possible to achieve faster movement speed or withstand greater load when the drive motor power is certain.
Applicable environment
Generally suitable for a variety of working environments. If the appropriate protective measures and materials are used, it can work stably in a normal indoor industrial environment, where the temperature range is usually between -20 ° C and 80 ° C. However, in some special environments, such as high humidity and corrosive gases, special protection may be required, such as the use of stainless steel rods or the addition of protective sleeves to prevent rust and corrosion.
Size & Interface
Quality Control
Ball screw production adhere to strict quality control system. In terms of raw materials, we select global quality suppliers, and strictly inspect alloy steel, ball and other materials with the help of spectral analyzer and hardness tester. In the production, the use of advanced automation equipment and technology, CNC grinding machine to ensure the processing accuracy, through real-time data monitoring and optimization of process parameters, and multi-node "self-check, mutual check, special inspection". When testing the finished product, a comprehensive performance test such as lead accuracy, positioning and repeated positioning accuracy, rated load, rigidity, etc. is carried out on a professional platform, and appearance and packaging are also checked. Follow international standards such as ISO 9001 certification, establish quality feedback mechanism, collect customer opinions, analyze quality data, continuous improvement, win market reputation with excellent quality, and provide reliable transmission solutions for precision machinery industry.
Application Cases
Widely used in CNC machine tools. In the feed system of CNC machine tool, the large lead ball screw can realize the high-speed cutting feed and improve the processing efficiency.
It is also used in automation equipment, such as material handling devices for automated production lines, joint movement of robots, etc. In these devices, the large lead ball screw can provide fast linear motion to meet the needs of high-speed and efficient production.
It can also be used for precision instruments, such as the adjustment mechanism of astronomical telescopes, precision displacement devices in medical equipment, etc., to play its advantages of high precision.
