Description
The heavy-duty robot platform has a 500 kg maximum load capacity, and 1800 mm body length, and a developable chassis.
Size: 1850*1300*600mm
Weight: 450kg
Speed: 0-3.2km/h
Loading Capacity: 500kg
Product Features
Heavy-duty robot platform introduction
C18 is a robot chassis that can reach a load of 500Kg requires a good suspension system and durability of the crawler. The material of the crawler is made of quality rubber embedded with Kovlar fiber, which can extend the service life of the crawler.
The 200mm crawler width can ensure the stability of the Robot platform kit. The main body length of the C18 robot chassis has reached 1825mm, which can basically carry various objects. The developable performance of the robot chassis can meet the different needs of users.
Product Params
| Self Weight | 450kg | Dimension | 1850*1300*600mm |
| Max. Loading Capacity | 500kg | Inner Space | 650*800*350mm |
| Ground Clearance | 190mm | Speed | 0-3.2km/h |
| IP Grade | IP54 | Max. Span | 800mm |
| Climbing Capacity | 30°( can climb stairs) | Track Width | 200mm |
| Max. Obstacle crossing | 320mm | Track Material | Rubber (Kovlar Embedded ) |
| Surface Treatment | Black Spray (Matte) | Drive Wheel Diameter | 190mm |
| Rated Torque | 2*285NM | Transmission Ratio | 1:30 |
| Suspension System | Christie * 12 Shock Absorption | Body Material | 304 Stainless Steel / Alloy Steel / Aluminum / Polymer Materials |
| Voltage | DC48V | Electric Motor | DC Brushless Motor |
| Max. Power | 3000w*2 | Standby Power Consumption | ≤50w |
| Brake Type (Optional) | Electric Brake | Braking Voltage | DC48V |
| Encoder (Optional) | 1000-2500TVL | Driver Model | 6050 |
| Control Distance | Open Space300mm | Number of Remote Control Channels | 9T(Used 3T) |
APPLICATION
1. Inspection
2. The ambulance
3. Education and scientific research
4. Designed as fire fighting robot
5. Exclusive photography
6. Special transportation
Service
1. 1 year warranty for main parts
During this period, in case of damage or breakdown, we will repair to replace spare part freely, while the buyer should bear overseas freight.
2. Spare Parts
Most of our spare parts are compatible with international standard. While, we offer spare parts all year round at cost price for our former clients.
3. Operation and Maintenance
We will offer you detailed operation manual, ensuring you can use it perfectly.
4. Online support
Video technical support
5. Online Service
your question will be answer within 24 hours during working days, 48 hours during holiday.
Pack
To ensure the ultimate protection of your products during transportation, we offer a comprehensive range of packaging solutions, including sturdy wooden boards, durable cartons, and high-quality foam packaging. These materials are specifically designed to safeguard your items from damage, providing a reliable barrier against the rigors of transit. By choosing our packaging options, you can rest assured that your products will arrive safely and in excellent condition.
Transport
We offer a range of freight methods to meet your needs, ensuring that your shipments are delivered efficiently. Typically, our deliveries arrive within 3 to 5 working days, allowing you to plan your operations with confidence. Whether you require standard shipping or expedited services, our reliable freight options guarantee timely arrival, helping you maintain your schedule and meet customer demands effectively.
