Product Description
Rubber track is a key component of rubber track chassis, which is vulcanized by rubber and reinforced materials such as fiber and steel wire. The rubber material gives the track good elasticity, can adapt to different terrain and effectively buffer vibration. The internal reinforcement material provides sufficient strength to ensure that the track will not easily break under the weight of the equipment and the tension during movement.
The driving wheels are primarily responsible for transmitting power to the tracks, enabling the chassis to move forward or backward. The tooth shape of the driving wheel meshes with the inner tooth of the track, and drives the track movement through rotation. The driving wheel is generally made of high-strength alloy steel with good wear resistance and toughness to withstand wear and impact caused by long-term power transmission.
Product Features
Good adaptability: The rubber track chassis can drive on a variety of complex terrain, such as muddy ground, sand, snow and rugged mountain roads. Its soft rubber track can be fitted to the ground, increasing the contact area with the ground, reducing the pressure, and effectively avoiding sinking.
Lower ground specific pressure: Compared with the traditional wheeled chassis, the rubber track chassis has a more uniform pressure distribution on the ground, and the ground specific pressure is small, so the damage to the ground is also low, which is very important in some places that need to protect the ground (such as lawns, farmland, etc.).
High stability: Due to the structural characteristics of the track chassis, its center of gravity is low, and the track has a long contact length with the ground, which can provide better stability during the driving process, especially in the case of climbing and crossing obstacles.
Good buffer performance: the elasticity of the rubber track itself can effectively buffer the vibration generated by the equipment during the driving process, reduce the damage caused by the vibration of the internal parts of the equipment, and provide a more comfortable working environment for the operator.
Product parameters
| name | argument | name | argument |
|---|---|---|---|
| Chassis length | 700mm | Chassis width | 600mm |
| Chassis height | 280mm | Track width | 100mm |
| Travel speed | 0-3.6 km/h | Motor power | ZD48VZD800W |
| Maximum load | 100 kg | Track material | Grade A natural rubber embedded with Kevlar fiber |
| Gear train material | Special synthetic polymer materials | Shafting material | Reinforced steel |
| Turning radius | Continuous 360 degree turn in place | Communication mode | CAN communication or 485 |
Our Factory
Product Certificate
Service
We have a highly professional service team. Team members are the elites in their respective fields, they have gone through strict selection and systematic training, have a wealth of professional knowledge and superb skills. Whether facing complex technical problems or daily service needs, they can quickly understand your needs with keen insight and provide the perfect solution with efficient action.
Pack
All the equipment in the factory is packaged in wooden cases combined with other cushioning materials. The wood itself has a certain elasticity, which can play a buffer role when it is impacted by external forces. Moreover, the wooden box can also be used with other buffer materials (such as foam, sponge, etc.) to further enhance the buffer effect. In the logistics and storage process, the wooden box can be stably stacked, make full use of space, and can withstand the pressure of the upper goods, to ensure the safety of the goods in the stacked state.
Transport
Whether it is a small package or a large shipment, whether it is local delivery or long-distance transportation, we meet your needs with a professional attitude and quality service. Safety is the core value of our transportation services. At the same time, the order has a perfect cargo tracking and monitoring system, you can know the transportation status of the goods anytime and anywhere through the mobile phone or computer, just like you personally accompany the goods on the journey. From the moment the goods are loaded until they arrive safely at their destination, we provide you with a transparent service throughout.
